Stainless Steel Nipple Drinker, Drinking Nipple

Request a Quote

About Us: http://pipefittingsltd.com/1-3-7-thread-pipe-nipple.html

Nipple Body
Nipple Pin
Orifice
Rubber O-ring
Button
Spring

Nipple drinkers are the core part of the livestock drinking system, which is made up of nipple body, nipple pin, orifice, rubber O-ring, button, and spring. The water nipple can be manufactured using different materials such as stainless steel, brass, and galvanized steel. It is constructed with customized thread types to meet all drinker pipes connection needs in the hog watering system. Featuring with durable construction, easy installation, and operation, these hog watering products are widely used for providing clean drinking for sows, sheep, cattle, piglets, etc. Because of the durable design, high-quality materials, and manufacturing techniques, our nipple waterers will be your right choice.

Key Features

Simple yet rugged design for long service life
O-ring used to provide a positive water seal, minimizing water losses
Provide all the water hogs need without any wasting
Easy operation: after biting, the water will flow out. When releasing, the nipple drinker will be returned to its closed position.
Even after millions of biting instances, the hog waterers will not be subject to breakage.

Shown below are some nipple drinkers. Customization service is always welcomed.

2. Pig nipple drinker

  Code Body
  length Pin Female
  Thread φ Water
  Outlet
  Diameter Weight

  CJ-ND601 63mm 8mm 1/2" 21mm 84g
2. Stainless steel nipple drinker

  Code Body
  length Pin Female
  Thread φ Water
  Outlet
  Diameter Weight

  CJ-ND615-5 79.5mm 14mm 1/2" 21mm 123g
2. Hog nipple

  Code Body
  length Pin Female
  Thread φ Water
  Outlet
  Diameter Weight

  CJ-ND620 55mm 5mm 1/2" 16mm 66g
2. Swine nipple drinker

  Code Body
  length Pin Female
  Thread φ Water
  Outlet
  Diameter Weight

  CJ-ND622-3 72mm 8mm 1/2" 3/4" 130g
2. Nipple waterer

  Code Body
  length Pin Female
  Thread φ Water
  Outlet
  Diameter Weight

  CJ-ND622-4 72mm 8mm 3/4" 3/4" 158g
2. Hog trainer nipple

  Code Body
  length Pin Female
  Thread φ Water
  Outlet
  Diameter Weight

  CJ-ND801 63.5mm 8mm 1/2" 21mm 87g
2. Sow nipple

  Code Body
  length Pin Female
  Thread φ Water
  Outlet
  Diameter Weight

  CJ-ND802 63.5mm 8mm 1/2" 22mm 86g
2. Sow trainer nipple

  Code Body
  length Pin Female
  Thread φ Water
  Outlet
  Diameter Weight

  CJ-ND803 63.5mm 8mm 1/2" 22mm 86g
2. Piglet nipple

  Code Body
  length Pin Female
  Thread φ Water
  Outlet
  Diameter Weight

  CJ-ND804 50mm 5mm 1/2" 13mm 51g
2. Stainless steel piglet nipple drinker

  Code Body
  length Pin Female
  Thread φ Water
  Outlet
  Diameter Weight

  CJ-ND805 55mm 5mm 1/2" 16mm 54g
2. Piglet trainer nipple

  Code Body
  length Pin Female
  Thread φ Water
  Outlet
  Diameter Weight

  CJ-ND807 64mm 12mm 1/2" 21mm 92g
2. Stainless steel nipple drinker

  Code Body
  length Pin Female
  Thread φ Water
  Outlet
  Diameter Weight

  CJ-ND808 46mm 12mm 1/2" 18.5mm 80g
2. Stainless steel nipple drinker

  Code Body
  length Pin Female
  Thread φ Water
  Outlet
  Diameter Weight

  CJ-ND808-1 46mm 10mm 1/2" 18.5mm 75g
2. Stainless steel nipple drinker

  Code Body
  length Pin Female
  Thread φ Water
  Outlet
  Diameter Weight

  CJ-ND808-2 46mm 8mm 1/2" 18.5mm 68g
2. Stainless steel nipple drinker

  Code Body
  length Pin Female
  Thread φ Water
  Outlet
  Diameter Weight

  CJ-ND810-1 31mm 8mm 1/2" 18.5mm 57g
2. Stainless steel nipple drinker

  Code Body
  length Pin Female
  Thread φ Water
  Outlet
  Diameter Weight

  CJ-ND810-3 33mm 8mm 1/2" 18.5mm 52g
2. Stainless steel nipple drinker

  Code Body
  length Pin Female
  Thread φ Water
  Outlet
  Diameter Weight

  CJ-ND813 35mm 8mm 1/2" 22mm 65g
2. Stainless steel nipple drinker

  Code Body
  length Pin Female
  Thread φ Water
  Outlet
  Diameter Weight

  CJ-ND814 63.5mm 8mm 1/2" 22mm 92g
Stainless nipple drinker for water bowl

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND815 40mm 7mm 1/2" 1/2" 80g
Stainless steel nipple drinker for feeding pan

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND818 41mm 8mm 1/2" 24Hex 104g
Stainless steel nipple drinker for feeding pan

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND818-1 41mm 8mm 1/2" 24Hex 85g
Stainless steel hog nipple drinker

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND819 52mm 9.6mm 1/2" Hex 22mm 94g
Stainless steel piglet nipple drinker

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND820 55mm 5mm 1/2" 21mm 61g
Nipple drinker

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND820B 55mm 5mm 1/2" 16mm 58g
Stainless steel nipple drinker

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND821-2 32mm 10mm 1/2" 21mm 68g
Stainless steel nipple drinker

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND822-1 72mm 8mm 1/2" 3/4" 135g
Stainless steel nipple drinker

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND822-2 72mm 8mm 3/4" 3/4" 149g
Stainless steel nipple waterer

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND823 35.5mm 14.5mm 1/2" 24mm 96g
Stainless steel nipple drinker

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND824 35.5mm 8mm 1/2" 24mm 94g
Stainless steel nipple drinker

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND826-1 39mm 15mm 1/2" 24mm 122g
Stainless steel water nipple

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND826-2 58mm 15mm 1/2" 24mm 174g
Stainless steel nipple drinker

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND827-1 37mm 17mm 1/2" 24mm 94g
Stainless steel water nipple

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND827-2 37mm 16.8mm 1/2" 22mm 93g
Stainless steel nipple waterer

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND828-1 70mm 8mm 1/2" 3/4" 124g
Hog nipple drinker

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND828-2 70mm 8mm 3/4" 3/4" 145g
Stainless steel nipple drinker

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND829-1 63.5mm 8mm 1/2" 18.5mm 73g
Pig nipple drinker

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND829-2 55mm 5mm 1/2" 16mm 55g
Stainless steel nipple drinker

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND830 35.7mm 8mm 1/2" 24mm 110g
Nipple drinker

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND831 35.7mm 8mm 1/2" 22mm 91g
Sow nipple

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND835-1 115mm 16mm 1/2" 28mm 222g
Stainless steel nipple drinker

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND835-2 79mm 14mm 1/2" 21mm 98g
Stainless steel nipple drinker for piglet

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND835-3 63.5mm 12mm 1/2" 18mm 77g
Stainless steel nipple drinker

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND836-1 42mm 12mm 1/2" 23mm 97g
Stainless steel nipple drinker

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND838 65mm 8mm 1/2" 20mm 126g
Wet feeder trainer valve

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND838-1 62mm 8mm 1/2" 20mm 117g
Wet feeder valve

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND842 68mm 8mm 1/2" 20mm 126g
Stainless steel nipple drinker

Code Body
length Pin Female
Thread φ Water
Outlet
Diameter Weight

CJ-ND844 36mm 8mm 1/2" 21mm 62g
