NC-E CO2 Laser Engraver

NC-E CO2 Laser Engraver
NC-E CO2 Laser Engraver
NC-E CO2 Laser Engraver
: http://lasercut-group.com/3-11-mc-e-b-co2-laser-marking-machine.html

The NC-E CO2 laser engraver is cost-effective and suitable for engraving small products. It features a power range of 60 to 100W, and because it processes materials using non-contact laser beams, the material incision is smooth and will not deform processed materials.

Applicable Materials: It can process most nonmetal materials and metal material including wood, paper, leather, cloth, plastics, rubber, ceramic, light metals and more.

Functions: It is mainly used for engraving, and can also be used to cut light metals, including a slope carving at any angle.

Technical parameters
Model NC-E6090
Laser Tube Power 60w/80w/100w
Laser Tube Type CO2 Laser Tube
Working Size 900*600mm
Cooling Way Water-cooled
Water Cooled Chiller CW3000/CW5200
Engraving Speed 0-60000mm/min.
Cutting Speed 0-40000mm/min.
Lens 3 Reflective Mirrors + 1 Focus Mirror
Control System Ruida
Air Pump Yes
Exhaust Fan Yes
Software Compatibility 100% Software Compatibility
Minimum Character Size English:1.0*1.0mm
Positional Accuracy ≤±0.01mm
Support Image Format PLT, AI, BMP, DST, DXF
Software Supported CorelDraw, Photoshop, Autocad, Tajima
Weight 380kg
Size 1550*1120*1200mm
Samples
Features
  • The laser engraver uses a square linear guide rail made by Taiwan Hiwin, with a service life of more than 20 years.
  • It has a specially designed exhaust system to protect the laser head and make the maintenance of laser head easier.
  • A specially designed focus lens ensures the laser beam has a smaller spot size and is more powerful.
  • The working table is an aluminum honeycomb panel with an exhaust inlet on the surface to suction workpieces tightly to the table surface.
  • Up and down worktable, this laser engraving machine is easy to process different workpieces.
