Liquid and Sauce Forming Filling Sealing Machine
Liquid and Sauce Forming Filling Sealing Machine, RZ500/600/1050
Application of Liquid and Sauce Forming Filling Sealing Machine
The liquid and sauce forming filling sealing machine is ideal for packing all kinds of liquid and think-liquid (sauce), fruit juice, seasoning sauce, tomato sauce, peanut butter, jam, chili sauce, hand sanitizer, liquid detergent, and others.
Main Features of Liquid and Sauce Forming Filling Sealing Machine
1. RezPack liquid and sauce forming filling sealing machine provides low cost high gain, high speed and efficiency.
2. The forming filling sealing machine comes with famous brand PLC control system and large touch screen, and thus is easy to operate.
3. The vertical packaging machine makes use of film drawing down system and horizontal sealing controlled by servo motor.
4. The liquid and sauce packaging machine minimizes the loss, by use of auto alarm design.
5. Equipped with feeding and measuring devices, the liquid and sauce forming filling sealing machine accomplishes feeding, measuring, filling, sealing, date printing, charging (exhausting), counting, and finished product delivery, in a continuous flow.
6. As to the way of bag making, the form fill seal machine can make pillow type bags and standup bags as per customer needs.
| Model | RZ-500 | RZ-600 | RZ-1050 |
| Capacity | Max. 50bags/min | Max. 60bags/min | Max. 30bags/min |
| Bag size | Width: 90-200mm | Width: 100-250mm | Width: 300-500mm |
| Length: 60-300mm | Length: 80-350mm | Length: 100-800mm | |
| Max film width | Max. 420mm | Max. 520mm | Max. 1050mm |
| Film thickness | 0.04-0.09mm | 0.04-0.09mm | 0.06-0.12mm |
| Power source | 2.2KW 220V 50HZ | 2.5KW 220V 50HZ | 6KW 220V 50HZ |
| Air consumption | 0.8Mpa 0.5m3/min | 0.8Mpa 0.4m3/min | 0.8Mpa 0.8m3/min |
| Dimension | L1530W970H1600 | L1500W1140H1540 | L2250W1800H2400 |
| Weight | 450kg | 680kg | 1000kg |
Thanks for visiting website of RezPack! As an experienced Chinese manufacturer of liquid and sauce forming filling sealing machine, RezPack is involved in the production and sale of a variety of pre-made pouch packing machinery, powder VFFS machine, bone and vegetable soup weighing packing production line, rice weigh fill seal production line, and more. RezPack is ISO9001 approved and offers excellent after sales service, in addition to high quality, CE certified, low priced packaging machinery. That is why RezPack products are so popular with customers from many different countries and regions such as Australia, New Zealand, the US, Canada, Mexico, Europe, South America, Europe, the Middle East, to name a few.
