TJJ04 Butyl Extruder Machine Manufacturer

TJJ04 Butyl Extruder Machine

: http://weedcontrolproduct.com/1-13-cyhalofop-butyl.html

This TJJ04 butyl extruder machine can effectively prevent glue from sticking to the frame or glue from seeping into coating axes when coating large aluminum frames. Its control system is hidden below the coating plate.

Parameter:

Input Voltage Total: 380V 50Hz
Total Power: 4.75KW
Squeeze Pressure: 10~17Mpa
Working Speed: 0~35m/min
Temperature: 90~150℃
Adjustable Range: 4~16mm
Pistons Diameter: ∮170mm
Air Pressure: 0.5~0.8Mpa
Outside Dimension: 2600×600×1650mm

Feature:

This butyl extruder machine adopts light-electricity inductor, PLC system and high temperature convey belt, which ensures uniform coating.
During the coating process of aluminum bar, the aluminum cannot swing towards the left and right because the aluminum is fixed by the wheel under the glue coating nozzle. The glass conveying process and coating process can be finalized automatically, so the operation is very convenient and stable.
Pressure reserve equipment is set for hydraulic pressure station, which makes sure the stable pressure supply during coating process, and the service life of hydraulic pressure system accessories indeed increase five times.
The exit of vertical glue cylinder is upward, which makes the gas can be discharged.
The pressure head is equipped with sealing ring, which prevent the glue from overflowing under high pressure extrusion, and also prevent deformation and abrasion.

Maintenance

Clean the equipment every day, and sweep the surrounding environment of equipment.
Check the electric wire joint of the equipment weekly, identify the points with potential errors.
Apply lubricating oil to transmission parts
Change the hydraulic fluid for hydraulic pressure system every year.
Sweep the dust for electronic control system and check the completeness.
