Desiccant Filling Machine Manufacturer

Desiccant Filling Machine

: http://plastic-processing.com/3-molded-desiccant-dryer.html

This desiccant filling machine is designed for aluminum spacer bending machines, and is controlled using a PLC control system. It can be used for the filling of automatic bent aluminum spacers and normal aluminum spacers.

Parameter:

Dimension: 1500×850×3650mm
Work pressure: 0.5~0.8MPa
Work Power: 220V
Flow control: about 24g/s
Filling speed: 8-12s/ (1m×1m 9a)
Aluminum spacer min: 6.5×5.5mm
Aluminum spacer max: 6.5×23.5mm
Weigh: 400Kg

Feature:

This desiccant filling machine can drill holes on the back of aluminum spacer, allowing it to be used for molecular sieve filling.
The filling height can be adjusted according to the aluminum spacer size.
The unique loading position helps to automatically fill the molecular sieve.

Equipment maintenance:

Check if there is water in the water separator before operating, as water needs to be regularly discharged.
Check if there are impurities or water in the filter, as the filter needs regular cleaning during operation.
Add oil for the air lubricator when needed.
According the equipment service conditions, change the drilling bit to an electric drill when the bit is dull.
Please do not adjust the speed regulating joint between the air cylinder
