Front Service LED Module

: http://smdledbulb.com/2-g8-led-bulb.html

When an LED display is mounted on a wall, front serviceable LED module can play a significant role. Because installation and maintenance are done from the front, there is no need to leave a serviceable channel behind the LED display. The traditional rear service module needs to reserve a serviceable channel of about 1 meter width, which makes the LED display highlight a lot of walls and affect appearance. The front serviceable module perfectly solves this problem.

In addition, the front serviceable module also offers unparalleled advantages when replacing a bad LED module. The traditional LED modules are screwed to the cabinet, which means that to replace a module, it is necessary to first remove all the screws, replace them with a new module, and then take all the screws back one by one, a process that can take half an hour.

However, the replacement of front serviceable LED module only needs to loosen the module on the two locks, replace the new module, and then tighten the two locks on module, the whole process less than a minute. This saves customers a lot of time and manpower.

Features:

There is no need to leave serviceable channel behind the cabinet, and the installation is not subject to site restrictions.
The replacement of module is fast and simple. You only need to unlock the module's lock, and then replace a new module.
Receiving card, power supply and other components can be maintained from the front. So there is no need doors on the rear of cabinet.
When the LED display needs to be installed on the wall or needs to be embedded in the wall, the front serviceable module is an ideal solution. On the one hand, maintenance personnel do not need to re-enter the wall for maintenance; On the other hand, the LED screen can be close to the wall surface. No or very little steel structure, so that you can save installation costs.
The pixel pitch of front serviceable LED display changes from P4.8 to P20, covering the pixel pitch of all mainstream outdoor advertising LED display. Haian products can meet the application needs of all outdoor advertising LED display.

Parameters:

SMD						DIP
Model	P4.81	P5.95	P6.67	P8	P10	P10	P16	P16	P20	P20
Pixel Pitch	4.81mm	5.95mm	6.67mm	8mm	10mm	10mm	16mm	16mm	20mm	20mm
Pixel Configuration	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B	1R1G1B	2R1G1B	1R1G1B	2R1G1B
LED Type	1921	1921	2727	3535	3535	346	346	346	346	346
Pixel Per SQM	43,222 dots	28,246 dots	22,477 dots	15,625 dots	10,000 dots	10,000 dots	3,906 dots	3,906 dots	2,500 dots	2,500 dots
Module Size	250x250mm	250x250mm	320x320mm	320x320mm	320x320mm	320x320mm	320x320mm	320x320mm	320x320mm	320x320mm
Module Resolution	52x52	42x42	48x48	40x40	32x32	32x32	20x20	20x20	16x16	16x16
Brightness	≥ 6500cd/m2	≥ 6500cd/m2	≥ 7000cd/m2	≥ 6500cd/m2	≥ 7000cd/m2	≥ 7000cd/m2	≥ 9000cd/m2	≥10000cd/m2	≥ 6500cd/m2	≥ 7000cd/m2
Viewing Angle	120/120	120/120	120/120	120/120	120/120	120/65	120/65	120/65	120/65	120/65
Driving Method	1/9	1/7	1/4	1/4	1/2	1/4	Static	Static	Static	Static
Minimum Viewing Distance	5m	6m	7m	8m	10m	10m	16m	16m	20m	20m
Gray Scale	65,536	65,536	65,536	65,536	65,536	65,536	65,536	65,536	65,536	65,536
Refresh Rate	1920Hz	1920Hz	1920Hz	1920Hz	1920Hz	1920Hz	1920Hz	1920Hz	1920Hz	1920Hz
Input Voltage (AC)	100V - 240V	100V - 240V	100V - 240V	100V - 240V	100V - 240V	100V - 240V	100V - 240V	100V - 240V	100V - 240V	100V - 240V
Frame Frequency	50 or 60 Hz	50 or 60 Hz	50 or 60 Hz	50 or 60 Hz	50 or 60 Hz	50 or 60 Hz	50 or 60 Hz	50 or 60 Hz	50 or 60 Hz	50 or 60 Hz
LED Blind Spot Rate	1/10,000	1/10,000	1/10,000	1/10,000	1/10,000	1/10,000	1/10,000	1/10,000	1/10,000	1/10,000
Lifetime	100,000 h	100,000 h	100,000 h	100,000 h	100,000 h	100,000 h	100,000 h	100,000 h	100,000 h	100,000 h
Protection Rate	IP65	IP65	IP65	IP65	IP65	IP65	IP65	IP65	IP65	IP65
Warranty	3 years	3 years	3 years	3 years	3 years	3 years	3 years	3 years	3 years	3 years
