CO2 Laser Power Supplies for 50-180W Laser Tubes
With 20 years of experience in the laser industry, HM Laser can offer CO2 laser tube power supplies that can maximize the effectiveness of the laser tube while helping extend its service life.
FDA Certificate
CE Certificate
Our laser tube power supply features an open circuit protection function. When the high voltage terminal is under open circuit condition or not firmly connected, the power supply will activate automatic protection function to efficiently avoid high voltage leakage. High-voltage discharge function ensures no static electricity generated when powering off.
Intelligent
The built-in control is used to communicate with motion controller (typically RUIDA motion control card) that allows up to 32 power supplies to be controlled through cascade connection. The working status of power supply is shown on the display of control panel, enabling operator to easily monitor the machine and determine the fault.
Compatible
By using active PFC circuit (power factor correction), our laser power supply can achieve high power factor. Any input voltage ranging within AC90-264V 50/60Hz can be accommodated with relative ease, thereby limiting the impact on the output current when mains voltage is largely changed.
Simple
The laser output power can be controlled by 0-5V analog signal or 5V PWM signal.
Stable
With an improved current control, the laser is generated with high stability and compatibility due to that the constant current is guaranteed over the entire input voltage range.
Features
- Wide input voltage range, universal for voltages of all countries
- Open circuit protection
- Stable output current
- Support fault display
Discover Our Models of CO2 Laser Tube Power Supplies
P2 CO2 Laser Tube Power Supply
- Input voltage: AC90-250V
- AC frequency: 47-63Hz
- Max. input power: 600W
- Max. input current (when 90V input): 5.5A
- Max. output voltage: 40kV
- Max. output current: 28mA
- Efficiency: ≥90% (full load)
- Mean time between failures (MTBF): ≥10,000 hours
- Response speed: ≤1ms (starting from the switching signal being sent to the output current reaching 90% of set current)
- Withstand voltage: input-output, input-shell: AC1500V 10mA 60
- Operating environment: temperature -10℃to 40℃, relative humidity ≤90%
- Cooling: force-air cooling (FAC)
- Applicable laser tube power: 50-80W
- Dimension (L×W×H): 235×144×104mm
- Weight: 2.15kg
- Shell color: silver gray
- Warranty: 18 months
P4 CO2 Laser Tube Power Supply
- Input voltage: AC90-250V
- AC frequency: 47-63Hz
- Max. input power: 650W
- Max. input current (when 90V input): 6A
- Max. output voltage: 45kV
- Max. output current: 32mA
- Efficiency: ≥90% (full load)
- Mean time between failures (MTBF): ≥10,000 hours
- Response speed: ≤1ms (starting from the switching signal being sent to the output current reaching 90% of set current)
- Withstand voltage: input-output, input-shell: AC1500V 10mA 60
- Operating environment: temperature -10℃to 40℃, relative humidity ≤90%
- Cooling: force-air cooling (FAC)
- Applicable laser tube power: 80-120W
- Dimension (L×W×H): 278×144×104mm
- Weight: 2.45kg
- Shell color: silver gray
- Warranty: 18 months
P6 CO2 Laser Tube Power Supply
- Input voltage: AC90-250V
- AC frequency: 47-63Hz
- Max. input power: 900W
- Max. input current (when 90V input): 8A
- Max. output voltage: 55kV
- Max. output current: 38mA
- Efficiency: ≥90% (full load)
- Mean time between failures (MTBF): ≥10,000 hours
- Response speed: ≤1ms (starting from the switching signal being sent to the output current reaching 90% of set current)
- Withstand voltage: input-output, input-shell: AC1500V 10mA 60
- Operating environment: temperature -10℃to 40℃, relative humidity ≤90%
- Cooling: force-air cooling (FAC)
- Applicable laser tube power: 130-180W
- Dimension (L×W×H): 330×144×104mm
- Weight: 3.2kg
- Shell color: silver gray
- Warranty: 18 months
Packaging
Double-layer foam packaging prevents damages caused by shock, pressure or collision during transportation.
