The DDB series 3D laser marking machine integrates a radio frequency laser (metal seal) imported from America or Germany and a high-speed scanning system with 3D dynamic focus and vibrating mirrors, specially designed to meet the demand of such industries like apparel, leather, artwork and craft and so on for fast cutting and engraving on non-metal materials. With the optimum use of the cutting-edge laser technology, the marking performance of this non-metal laser marking machine is stunningly breathtaking, even doubling the added value of the original products.

Applications
The 3D laser marker well suitable for the non-metal materials like apparel, leather, rubber, wooden board, bamboo, organic glass, ceramic tile, plastics, marble, jade, crystal, cloth, etc. This CO2 laser marking machine is often used as leather laser marking machine, cloth laser marking machine,plastics laser marking machine, art craft manufacturing equipment, etc.

Features
  • The totally enclosed and maintenance-free laser optical system installed in the 3D marking machine is handy to install without any adjustment.
  • The metal-sealed radio frequency laser imported from America or Germany possesses strong and stable power, high-quality laser spot, and long service life.
  • The tri-axial laser scanning system presents easy and accurate installation, compact and solid structure, effective dust prevention, strong anti-jamming capability and other great advantages. Cooling for the vibrating mirror motor and driver board is taken into full consideration in advance, ensuring its stability in long-time running.
  • The dual cooling system integrating radio frequency laser water cooling and beam expander water cooling ensures the laser marker’ stability in operation and longer service life.
  • The controller card is based on USB interface, and the 3D laser marking machine supports off-line operation, 4-axis (X, Y, Z, R) stepper motor, and external control on start and stop.
  • Hunst Laser originally creates the 3D marking technology, making it possible to precisely mark on non-flat surface with an up to 10cm vertical height difference.
Technical Parameters of 3D Laser Marking Machine:
Model DDB-100/DDB-150/DDB-200
Laser power 100W/150W/200W
Laser type CO2 laser (metal seal)
Machine power 6KW
Minimum character 1mm
Repeat position accuracy ±0.02mm
Marking speed 7000mm/s
Marking scope 30*30/50*50/60*60/80*80/100*100/120*120mm (optional)
Operating voltage AC220V/11V,30A ,50Hz/60Hz
Cooling type Water cooling and protection system
Acceptable graphic format PLT, PCX, DXF, BMP, AI
Average focal spot size 190um~450um
Dynamic axis response time < 4ms
Net weight 420kgs
