1QL Metric Male 74° / Boned Seal Hose Adapter
Application: for use with hydraulic braided hoses
Materials:- Stainless steel metric male 74°/ boned seal hose adapter
- Carbon steel metric male 74°/ boned seal hose adapter
| Part No. | Thread | Tube O.D | Dimensions | ||||||
| E | F | D1,D2 | A | B | L | S1 | S2,S3 | ||
| 1QL-12-10 | M12×1.5 | M10×1 | 6 | 15.7 | 8 | 29.5 | 15 | 14 | |
| 1QL-14-12 | M14×1.5 | M12×1.5 | 8 | 17 | 12 | 36.5 | 17 | 17 | |
| 1QL-16-14 | M16×1.5 | M14×1.5 | 10 | 18 | 12 | 38 | 19 | 19 | |
| 1QL-18-16 | M18×1.5 | M16×1.5 | 12 | 18 | 12 | 38 | 22 | 22 | |
| 1QL-22-18 | M22×1.5 | M18×1.5 | 14 | 19.5 | 12 | 39.5 | 24 | 27 | |
| 1QL-27-22 | M27×1.5 | M22×1.5 | 18 | 20 | 14 | 44 | 30 | 32 | |
| 1QL-30-27 | M30×1.5 | M27×2 | 20 | 23 | 16 | 50 | 34 | 36 | |
| 1QL-33-27 | M33×2 | M27×2 | 22 | 25 | 16 | 55 | 34 | 41 | |
| 1QL-36-33 | M36×2 | M33×2 | 25 | 25 | 18 | 56 | 41 | 41 | |
| 1QL-39-33 | M39×2 | M33×2 | 28 | 26 | 18 | 57 | 41 | 46 | |
| 1QL-45-42 | M45×2 | M42×2 | 34 | 28.5 | 20 | 62.5 | 50 | 50 | |
