SN-V24-065S 24VDC 65W LED Power Supply
Features
- This strip LED power supply has a size of 400×24.5×22mm.
- It adopts high input voltage of 200VAC-240VAC.
- The power efficiency is more than 90%.
- This LED power supply has built-in power factor corrector with a power factor over 0.95.
- The power supply has short-circuit protection, self-recovery of short-circuit release, over-voltage protection, over-current protection and other functions.
- The ripple noise is lower than 60mVp-p, without stroboscopic effect.
- The total harmonic distortion is less than 15%.
- The ingress protection is IP20, being suitable for indoor LED lights.
Basic Parameters
| Input voltage | 200~240VAC 50/60Hz |
| Input current | 0.4A Max |
| Output voltage | 24VDC |
| Output current | 2.7A Max |
| Output power | 65W |
| Power factor | >0.95 |
| Power efficiency | 90% |
| Size | 400×24.5×22mm |
