ESD-V24-065S 24VDC 65W Dimmable LED Power Supply
Features
- This dimmable LED power supply has a internationally universal full range input (100~277VAC).
- It is equipped with built-in intelligent load identification CPU (the light can be dimmed completely).
- The LED power supply has short-circuit protection, over-temperature protection, overload protection and other functions to make it more secure to use.
- The power efficiency is up to over 90%.
- The LED power supply has three-in-one dimming function (0-10V DC, PWM, resistance).
- This dimmable power supply has a built-in power factor corrector.
Basic Parameters
| Input voltage | 100~277VAC 50/60Hz |
| Input current | 1.0A Max |
| Output voltage | 24VDC |
| Output current | 2.8A Max |
| Output power | 65W |
| Power factor | >0.95 |
| Power efficiency | 90% |
| Size | 363×34×22.5mm |
