EMC02 X5070 Carbide 2 Flute End Mill for High Hardened Steels

EMC02 X5070 Carbide 2 Flute End Mill for High Hardened Steels
EMC02 X5070 Carbide 2 Flute End Mill for High Hardened Steels
EMC02 X5070 Carbide 2 Flute End Mill for High Hardened Steels
: http://metalworking-tool.com/4-2-emc02-x5070-carbide-2-flute-for-high-hardness-steel-long-model.html
  • Designed to machine tool steel, alloy steel, mold steel and other materials with hardness up to HRC70
  • Oerlikon Balzers coating offers superior hardness and heat resistance
  • Increased feed rates
Application
Product Specifications
Coating AITISIN HRC HRC50/65/70
Helix Angle 45° Shank Cylindrical H6
Material IMC™ UMG Carbide Rod Tolerance on Cutting Diameter 0-0.030
X5070 Carbide Square End Mills, 2 Flutes （UNT-EMC02）
Unit: mm
UNT EDP # Click to Order Mill Dia.
D1 		Shank Dia.
D2 		Flute Length
L1 		Effective Length
L3 		O.A.L.
L2 		Flutes
EMC02010075 1.0 4 2.5 4 75 2
EMC02015075 1.5 4 4 6 75 2
EMC02020075 2.0 4 5 8 75 2
EMC02025075 2.5 4 6 10 75 2
EMC02030075 3.0 4 8 12 75 2
EMC02040075 4.0 4 10 16 75 2
EMC020100756 1.0 6 2.5 4 75 2
EMC020150756 1.5 6 4 6 75 2
EMC020200756 2.0 6 5 8 75 2
EMC020250756 2.5 6 6 10 75 2
EMC020300756 3.0 6 8 12 75 2
EMC020400756 4.0 6 10 16 75 2
EMC02050075 5.0 6 13 20 75 2
EMC02060075 6.0 6 15 20 75 2
EMC02060100 6.0 6 15 24 100 2
EMC02080075 8.0 8 20 24 75 2
EMC02080100 8.0 8 20 32 100 2
EMC02100100 10.0 10 25 40 100 2
EMC02120100 12.0 12 30 45 100 2
EMC02080150 8.0 8 24 36 150 2
EMC02100150 10.0 10 30 45 150 2
EMC02120150 12.0 12 36 50 150 2
EMC02160150 16.0 16 48 60 150 2

• End mills with non-standard sizes or specifications not listed above can be customized according to customer needs.
