1JN JIC Male Hose Adapter
Application: for use with hydraulic braided hoses
Materials:- Stainless steel JIC male hose adapter
- Carbon steel JIC male hose adapter
| Part No. | Thread | Dimensions | |||||
| E | F | A | B | L | S1 | ||
| 1JN-04 | 7/16"×20 | Z1/4"×18 | 14 | 15 | 35 | 17 | |
| 1JN-05-04 | 1/2"×20 | Z1/4"×18 | 14 | 15 | 35 | 17 | |
| 1JN-06 | 9/16"×18 | Z3/8"×18 | 14.1 | 16 | 36 | 19 | |
| 1JN-08 | 3/4"×16 | Z1/2"×18 | 16.7 | 19.5 | 44 | 24 | |
| 1JN-10-08 | 7/8"×14 | Z1/2"×18 | 19.3 | 19.5 | 47 | 24 | |
| 1JN-12 | 1.1/16"×12 | Z3/4"×18 | 21.9 | 19.5 | 51.5 | 30 | |
| 1JN-16 | 1.5/16"×12 | Z1"×11.5 | 23.1 | 25.5 | 58.5 | 36 | |
| 1JN-20 | 1.5/8"×12 | Z1.1/4"×11.5 | 24.3 | 26.5 | 63.5 | 46 | |
| 1JN-24 | 1.7/8"×12 | Z1.1/2"×11.5 | 27.5 | 27.5 | 70 | 50 | |
| 1JN-32 | 2.1/2"×12 | Z2"×11.5 | 33.9 | 27.5 | 78.5 | 65 | |
