Double-layer Extruding Film Casting Machine

Double-layer Extruding Film Casting Machine

Application of Double-layer Extruding Film Casting Machine JDSJ
This machine set is used for producing LDPE or LLDPE stretch film.
If the machine adopts double screws, the two hoppers should use different type of material, one side of the extruded stretch film is adhesive and the other side is normal. It is widely used for packing architecture and hardware parts etc.

Features of Double-layer Extruding Film Casting Machine JDSJ
1. Screw and cylinder are all made of 38CRMOALA alloy and treated by nitrogen. It has an advantage of corrosion resistance and endurance etc.
2. The cooling device adopts cycle water cooling; provide the best transparent effect of the stretch film.
3. Take-up equipment adopts with friction type rewinding, and equipment with edge correcting device to ensure the quality.

Note: All equipments supplied by our company are not include attached unit(water, air, electricity)

Technical Parameters of Double-layer Extruding Film Casting Machine JDSJ
Type JDSJ-50x2
Screw Dia. φ50mmx2
Length/Dia. of Screw 30:1(L/D)
Product Width 200-550mm
Product Thickness 0.015-0.03mm
Output 40kg/h
Main Motor Power 7.5kwx2
Heating Power 30kw
Machine Weight 3.5T
Machine Dimension 5600x2600x1800mm
Power Supply 380/3/4/50(Volt/Ph/Line/Hz)
