Automatic L-Shaped Sealer and Shrink Tunnel
Features
1. The automatic L-shaped sealer and shrink tunnel adopts temperature compensating solid state controllers to keep the working stable.
2. Belt conveyor is designed with variable speed and the speed can be adjustable.
3. The stainless-steel heater with top and side heating mode is able to work for a long time.
4. The automatic sealer and shrink tunnel quickly change the seal wire to ensure the quick assembly.
5. It is equipped with double magnetic hold-down device to promise stable working.
6. It is able to work with all types of shrink films, especially for non-PVC, polyolefin films.
| Model | FQL450LA | FQL450A |
| Power Supply | 1 Phase 220V/50-60Hz | |
| SEAL SIZE | 560×450mm | 600×450mm |
| Product Size | L520×W410mm | L580×W420mm |
| Conveyor Loading | 20KG MAX | 25KG MAX |
| Machine Size | 1600×835×1470mm | 1450×670×1000mm |
| Weight | 280KG | 110KG |
| Shrink film | POF, PVC, PP, PE | |
| Model | BSD4020A | BSD4525A |
| Power Supply | 1 Phase 220V/50-60Hz | 3 Phase 380V/50Hz |
| Heater power | 6.5KW adjustable | 8KW adjustable |
| Conveyor Speed | 0-15m/min | 0-15m/min |
| Tunnel Size | 1000×400×200mm | 1000×450×250mm |
| Shrink Product Size | 350×160mm | 400×210mm |
| Coneyor loading | 25Kg Max | 25Kg Max |
| Machine Size | 1240×660×1320mm | 1250×71×1370mm |
| Weight | 90KG | 120KG |
| Shrink film | POF, PVC, PP | |
