72011M BSP Banjo (British Standard Pipe)
Application: for use with hydraulic braided hoses
Materials:- Stainless steel BSP banjo (British Standard Pipe)
- Carbon steel BSP banjo (British Standard Pipe)
| Part No. | Tube O.D. | Hose Bore | Dimensions | |||||
| DN | DASH | A | d | D | H | |||
| 72011-04-04 | G1/4''×19 | 6 | 04 | 19.5 | 13.3 | 24 | 15 | |
| 72011-04-05 | G1/4''×19 | 8 | 05 | 19 | 13.3 | 24 | 15 | |
| 72011-04-06 | G1/4''×19 | 10 | 06 | 19.5 | 13.3 | 24 | 15 | |
| 72011-06-04 | G3/8''×19 | 6 | 04 | 22 | 16.7 | 29 | 20 | |
| 72011-06-05 | G3/8''×19 | 8 | 05 | 22.5 | 16.7 | 29 | 20 | |
| 72011-06-06 | G3/8''×19 | 10 | 06 | 22 | 16.7 | 29 | 20 | |
| 72011-06-08 | G3/8''×19 | 12 | 08 | 22.5 | 16.7 | 29 | 20 | |
| 72011-08-05 | G1/2''×14 | 8 | 05 | 27.5 | 21 | 38 | 25 | |
| 72011-08-06 | G1/2''×14 | 10 | 06 | 27.5 | 21 | 38 | 25 | |
| 72011-08-08 | G1/2''×14 | 12 | 08 | 28 | 21 | 38 | 25 | |
| 72011-08-10 | G1/2''×14 | 16 | 10 | 28.5 | 21 | 38 | 25 | |
| 72011-10-10 | G5/8''×14 | 16 | 10 | 30 | 23 | 40 | 27 | |
| 72011-12-10 | G3/4''×14 | 16 | 10 | 31.5 | 26.5 | 48 | 31 | |
| 72011-12-12 | G3/4''×14 | 20 | 12 | 32 | 26.5 | 48 | 31 | |
| 72011-16-08 | G1''×11 | 12 | 08 | 40 | 33.3 | 60 | 42 | |
| 72011-16-12 | G1''×11 | 20 | 12 | 40 | 33.3 | 60 | 42 | |
| 72011-16-16 | G1''×11 | 25 | 16 | 41 | 33.3 | 60 | 42 | |
