Fan Coil Unit

: http://hlthermostat.com/1-1-4-wireless-fan-coil-thermostat/index.html

Fan Coil Unit is a kind of end equipment of air conditioning system, consists of small fan, electric motor and coil. Chilled or hot water exchanges heat with air outside the pipe when flowing through the coil, to cool or heat air indoor. WARM provide ceiling ducted type, cassette type and high wall mounted type of Fan Coil Unit sorted by different installing methods for you to choose.

Features of Fan Coil Unit

Fan Coil Unit is able for multi-gear transmission or infinitely variable speeds according to customer’s need.
BLDC motor applied, which effectively increases working efficient, it features only 10~20% power consumption of common fan coil unit, which helps save cost.
Equips abnormal load protection, abnormal current protection, etc., to ensure stable running.
The device features low vibration and low noise when running.

Specifications

Types Comparison	Type		FP-34	FP-51	FP-68	FP-85	FP-102	FP-136	FP-170	FP-204	FP-238
Rated Air Flow Rate (m³/h)	High		340	510	680	850	1020	1360	1700	2040	2380
	Medium		255	383	510	638	765	1020	1275	1530	1785
	Low		170	255	340	425	510	680	850	1020	1190
Cooling Capacity (W)	High Speed	Total Heat	1888	2795	3709	4625	5518	7046	8838	10578	12318
	High Speed	Sensible Heat	1310	1926	2528	3149	3722	4863	6073	7242	8389
	Medium Speed	Total Heat	1661	2432	3251	4030	4785	6182	7739	9158	10716
	Medium Speed	Sensible Heat	1099	1603	2133	2629	3148	4072	5082	6002	7040
	Low Speed	Total Heat	1321	1933	2568	3182	3778	4900	6136	7281	8472
	Low Speed	Sensible Heat	839	1231	1623	2005	2379	3120	3895	4609	5408
Heating Capacity (W)	High Speed		3143	4556	5997	7378	8707	11410	14254	16789	19476
	Medium Speed		2567	3732	4915	6054	7154	9395	11731	13845	16064
	Low Speed		1879	2746	3622	4471	5295	6975	8731	10296	11953
Noise dB(A)	Low Static Pressure		37	39	41	43	45	46	48	50	52
	High Static Pressure		40	42	44	46	47	48	50	52	54
	Extremely High Static Pressure		41	44	46	47	48	50	52	54	56
Water Flowing Rate(L/h)			325	481	638	796	949	1212	1520	1819	2119
Electric Motor	Power Supply		220V 1ph 50Hz
	Motor Number		1	1	1	1	1	2	2	2	2
	Low Static Pressure Input Power(W)		37	52	62	76	96	134	152	189	228
	High Static Pressure Input Power(W)		44	59	72	87	108	156	174	212	253
	Extremely High Static Pressure Input Power(W)		49	66	84	100	118	174	210	250	300
