Hybrid Diamond Scribing Wheel

Description
The hybrid diamondscribing wheel uses high quality PCD material made by Element Six andSumitomo.  It is manufactured withunique high precision processing technology and its cutting edge is processed with a matt finish.

Features
1. With unique choice of material, the hybrid diamond scribing wheel
has a high cost performance.  It is the ideal choice for cutting touchscreen.
2. The hybrid diamond scribing wheel
has various cutting edges, making it widely applicable.  It is suitable to cut glasses made fromdifferent materials.  The hybrid diamondscribing wheel is the ideal substitutefor the tungstencarbide scribing wheel as its service life is three times that of the tungstencarbide scribing wheel.
3. Our hybrid diamond scribing wheel can cut the ITO conducting film and theglass at the same time when cutting touch screen.

Application
The hybrid diamond scribing wheel is used in high end LCD production lines,LCD panels, substrate glass, and glass tube of touch screens.

Technical Specifications

Description

Specification

OD(mm)

ID(mm)

T(mm)

V(°)

Hybrid Diamond Scribing Wheel

1.20

0.50

0.65

60-163

2.00

0.80

0.65

2.50

0.80

0.65

3.00

0.80

0.65

3.20

1.20

0.65

4.00

1.30

0.65

5.00

1.40

0.65

6.00

1.50

0.65


Material
The hybrid diamond scribing wheel uses high quality PCD material made byElement Six and Sumitomo.

Packaging
The hybrid diamond scribing wheel
is packaged in a plastic case.

World is a diamond scribing wheel manufacturer and supplier, based in China.  We offer hybrid diamond scribing wheels, PCDexternal grooving tools, and tungsten carbide supported die blanks.  Our high quality products are offered atcompetitive prices.  The full chain ofmanufacturing lapping machines and PDC cutters can be completed in China, even inone city.  Our lower manufacturing costsaves your purchasing cost.  More detailsof each product are shown on the page with description.
