Key Machine 222-A
Key Machine 222-A
1. The 222-A key machine is the newest model, with solid structure andhigh accuracy. It’s easy to operate cutting all kinds of saw-teeth keys.
2. The distance between the vises is extendablecutting long handle keys.
3. The vise is four-side rotary to clamp different types of keys.
4. The vise assembly of the key machine 222-A moves in a straight line to cutkeys, the maximum cutting length is 64mm.
Configurations of Key Machine 222-A
1)Motor
AC, available in different voltages and frequencies, 150W
2) HSS cutter: NO.0013#C
110T double thick titanium cutter specification: 80×5×16×82°×110T
3) Adjusting: The 222-A key machine is set with guide steppingmicro-adjustment device
4) Vise: 4-way jaws.
Technical Specifications of Key Machine222-A
| Motor | AC 220V/110V 50/60Hz 150W |
| Cutter | HSS NO.0013#C |
| Adjustment | Set with guide stepping micro-adjustment device |
| Vise | 4-way jaws. |
| Actual Dimension | 44×38.5×36cm |
| Carton Dimension | 50×37×37cm |
Wenxing is an experienced key machine manufacturer and supplier in
