High Speed Multifunction Pillow Type Packaging Machine
High Speed Multifunction Pillow Type Packaging Machine
The high speed multifunction pillow type packaging machine adopts human-computer interface, making the setting of parameter more convenient. It is controlled by the dual frequency converter (Customers can also choose servo motor). Once the length of the bag is set, the bag is cut off. There is no need of idling regulation, which saves time and film. The highly sensitive photoelectric color code tracking system makes the sealing more accurate. The positioned stop function of the equipment ensures that the film will not stick on the knife, thus saving material. The temperature is controlled independently by the PID controller, enabling our product to apply to various packaging materials.
With a simple drive system, our product runs more stably and it is more convenient to maintain. It also has a self-diagnostic function. In addition, all controls are realized by software, which facilitates function adjusting and technical upgrade, ensuring that the machine remains in the advanced level.
Specifications
Model | QH-280 | QH-350 | QH-450 | QH-550 |
Max. Width of the Packaging Film | ||||
Length of the Produced Bag | 90-220 or 150-320 | 90-220 or 150 | 130 | 180 |
Width of the Produced Bag | 50 | 50 | 50 | 50 |
Max. Height of the packaged object | ||||
Max. Diameter of the Film Roll | ||||
Packaging Speed | 50-250bag/min | 50-250bag/min | 40-200 bag/min | 30-200 bag/min |
Voltage | 220V, 50Hz | 220V/380V, 50Hz | ||
Power | 2.5kw | 3kw | ||
Dimensions | L | L | ||
Total Weight | ||||
Remark | Inflating and date printing device can be equipped. | |||
