DRV Worm Gear Speed Reducer Model Selection

: http://motor-gearbox.com/drv-worm-gear-reducer-model-selection.html

The following is the model selection table of DRV series electric motor and speed reducer.

NMRV+NMRV	i=i1×i2	100	150	200	250	300	400	500	600	750	900
NMRV+NMRV	n₂	14	9.3	7	5.6	4.7	3.5	2.8	2.3	1.9	1.6
DRV025/030	0.06kW		10*15	10*20	10*25	10*30	20*20	20*25	20*30	30*25	30*30
DRV025/030	0.09kW	10*10
DRV025/040	0.06kW					10*30	10*40	20*25	20*30	30*25	30*30
DRV030/040	0.06kW					10*30	10*40	20*25	20*30	25*30	30*30
DRV030/040	0.09kW					10*30
DRV030/050	0.06kW										30*30
	0.09kW						10*40	10*50	20*30	25*30	30*30
	0.12kW					10*30	10*40	10*50
	0.18kW					10*30
DRV030/063	0.06kW
	0.09kW										15*60
	0.12kW							10*50	15*40	15*50
	0.18kW					7.5*40	10*40	10*50
DRV040/075	0.06kW
	0.09kW
	0.12kW										30*30
	0.18kW								20*30	25*30	30*30
	0.25kW					10*30	10*40	10*50
	0.37kW					10*30	10*40
DRV040/090	0.06kW
	0.09kW
	0.12kW
	0.18kW										15*60
	0.2 5 kW								15*40	15*50	15*60
	0.37kW					7.5*40	10*40	10*50	15*40
DRV050/110	0.12kW
	0.18kW
	0.2 5 kW
	0.37kW									25*30	30*30
	0.55kW					10*30	10*40	10*50	15*40	25*30
	0.75kW					10*30	10*40
DRV063/130	0.25kW
	0.37kW
	0.55kW							10*50		25*30
	0.75kW							10*50	15*40	25*30	30*30
	1.1kW					10*30	10*40	10*50
	1.5kW					10*30	10*40
DRV063/150	0.25kW
	0.37kW
	0.55kW
	0.75kW							10*50	15*40	25*30	30*30
	1.1kW		10*15	10*20	10*25	10*30	10*40	10*50	15*40	25*30
	1.5kW		10*15	10*20	10*25	10*30	10*40	10*50	15*40
DRV025/030	0.06kW	40*30	50*30	60*30	60*40	60*50
DRV025/030	0.09kW
DRV02 5/040	0.06kW	40*30	50*30	60*30	60*40	60*50		50*80		50*100
DRV030/040	0.06kW	40*30	50*30	60*30	60*40	60*50	80*40	80*50		50*100
DRV030/040	0.09kW
DRV030/050	0.06kW	40*30	50*30	60*30	60*40	60*50		80*50	80*60
	0.09kW
	0.12kW
	0.18kW
DRV030/063	0.06kW		30*50	30*60	60*40	60*50		80*50		50*100
	0.09kW	40*30	30*50
	0.12kW
	0.18kW
DRV040/075	0.06kW				60*40	60*50		80*50		100*50
	0.09kW		50*30	60*30	60*40
	0.12kW	30*40
	0.18kW
	0.2 5 kW
	0.37kW
DRV040/090	0.06kW					60*50		80*50		100*50
	0.09kW				60*40	60*50		80*50
	0.12kW		30*50	30*60	60*40
	0.18kW	30*40	30*50
	0.25kW
	0.37kW
DRV050/110	0.12kW					60*50		80*50		100*50
	0.18kW			60*30	60*40
	0.25kW	30*40	50*30	60*30
	0.37kW	30*40
	0.55kW
	0.75kW
DRV063/130	0.25kW				60M0	60*50		80*50		100*50
	0.37kW	30*40	50*30	60*30
	0.55kW	30*40
	0.75kW
	1.1kW
	1.5kW
DRV063/150	0.25kW			60*30	60*40	60*50		80*50		100*50
	0.37kW			60*30	60*40	60*50
	0.55kW			60*30	60*40
	0.75kW	30*40
	1.1kW
	1.5kW
