HD/SB Series Liquid Transfer Drum Pump

: http://defupump.com/liquid-transfer-drum-pump.html

The liquid transfer drum pump is a kind of barrel pump. The pump tube can be directly put into the drum to pump liquid. As per different transferring liquid, the flow passage components can be made from Aluminum Alloy, Stainless Steel, PP, RPP, PVDF Material. The driving motor can be single phase common motor, Ex-proof motor, brushless motor & high-speed motor for option. This drum pump features easy use, maintenance and high efficiency.

Applications

This drum pump is widely used to transfer some low-viscosity liquids in extensive fields of petrochemical, refinery, food, petro oil, marine, pharmacy, filling station etc.

Pump Performance

Max. temperature	100℃(212℉)
Max. viscosity	1200CPS
Max. power	1.1KW(1100W)
Max. speed	12000r/min
Max. flow rate	165L/min
Max. head	28m
Pump tube length	700mm(27''), 1000mm(39"), 1200mm(47"), 1500mm(60")
Pump tube material	PPHT - Polypropylene	Acid and alkaline substances, like acetic acid, ammonium, sodium hydroxide.
	PVDF - Polyvinylidene Fluoride PVDF	Highly corrosive and toxic substances, like hydrofluoric acid, sulfuric acid, nitric acid, sodium hypochlorite
	SS - Stainless Steel 304 or Stainless Steel 316L	Flammable or inflammable substances: diesel oil, gasoline, all kinds of oil, inhibiting agents and alcohol.
	AL - Aluminum Alloy	Weakly corrosive sewage, diesel oil, low-viscosity oil and lubricating oil.

Motor Performance

Motor Model	Motor Model Meaning	Voltage	Speed	Frequency	Power
HD-E2-V	Variable speed control motor	220V	0-10000r/min	50-60Hz	800W
HD-EX2-V(SB-3)	Explosion-proof motor	220V	12000r/min	50-60Hz	880W
HD-A1	Air motor		0-10000r/min	3-7bar	375W
SB-1100W	High-speed motor	220V	10000r/min	50-60Hz	1100W
SB-880W	High-speed motor	220V	10000r/min	50-60Hz	880W
SB-550W	High-speed motor	220V	8000r/min	50-60Hz	550W
