Atomizing Dampener

Atomizing Dampener
Request a Quote

The atomizing dampener is a specialized machine used to add a trace amount of water to the surface of grains.

Advantages
1. As the name implies, this machine converts liquid water into small water drops with diameter of smaller than 100 microns, thus realizing uniform moisture addition.

2. Before grinding process, a 30-minute-long dampening treatment is necessary, and the moisture addition rate is 0.2%-0.5% accordingly. The water is added to the bran rather than the wheat endosperm, so the bran will be softened to improve its cellulose's resistance to mechanical force. As a result, when grinding wheat, its bran will keep intact, and this results in improved flour quality in several aspects. For example, the bran speck quantity will be reduced, the flour color will be whitened, and the ash content will be cut down.

Owing to the above, this atomizing dampener is the perfect choice for you.

Technical Parameters
Model Max. throughput (t/h) Water requirement (L/h) Water drop diameter (μm) Moisture addition rate (%) Power supply Power (kW) Weight (kg)
FZW20-300 3 20 10-100 0.2-0.5 220V 0.05 32
FZW25-300 4 25 10-100 0.2-0.5 0.05 42
FZW50-300 8 50 10-100 0.2-0.5 0.1 48
FZW50-380 10 50 10-100 0.2-0.5 0.1 62
FZW75-380 15 75 10-100 0.2-0.5 0.2 65
FZW100-380 20 100 10-100 0.2-0.5 0.2 98
FZW150-380 30 150 10-100 0.2-0.5 0.3 130

Related Names
Wheat Mixing Machine | Water Spraying Mixer | Flour Mill Water Conditioner
