LYD72MF Mono Solar Panel

: http://solar-pumping.com/4-solar-panels.html

Inquiry

Features

72 monocrystalline cells
Double sided tempered glass
Size: 1992*1002*7mm
Max. Module efficiency: 20.5%
Aluminum alloy frame
More energy output
30% more energy output due to the design with solar cells on both sides of the module
Glass offers good heat dissipation performance and increased power generation
Trustworthy
Fully symmetrical structure, no cracking risk
PVB package with extremely low water vapor permeability, will not cause component delamination and cracking
30-year performance warranty
10-year quality warranty

Description

This 72-cell double-glass monocrystalline photovoltaic module is fitted with aluminum frame which makes it easy to install and transport. With 72 high-efficiency PERC cells, it can generate electricity from either side of the panel improving the generating efficiency by about 30%. The reinforced PVB film on both sides and the extra clear tempered glass can provide higher solar transmittance, enabling excellent water resistance, better heat dissipation and longer service life of at least 30 years.

Technical Parameters

Mechanical Parameters
Length	1992mm
Width	1002mm
Weight	32kg
Thickness	7mm(J-box and Frame not included)
Area	1.996m2
Individual Leadwire	4mm2
Connectors	MC4/MC4 equivalent
Junction Box	IP68
Cell type	Monocrystalline cell
Frame material	30mm Aluminum alloy
Front glass	Extra clear tempered glass，3.2mm
Back glass	Tempered glass 3.2mm
Encapsulation	PVB
Load rating	Static: 5400Pa Wind: 2400Pa

Module numbers and ratings at standard test conditions(1000W/m2, AM 1.5, 25°C)

Nominal values		375	380	390	405	410
Nominal power (-0/ 5W)	PMPP (W)	375	380	390	405	410
Voltage at Pmax	VMPP (V)	38.5	38.7	38.2	38.6	38.8
Current at Pmax	IMPP (A)	9.75	9.84	10.23	10.50	10.59
Open circuit voltage	VOC (V)	45.1	45.3	44.6	45.0	45.1
Short circuit current	ISC (A)	10.23	10.32	10.87	11.14	11.23
Module efficiency	%	18.8	19.0	19.5	20.3	20.5
Operation temperature	℃	-40~ 85	-40~ 85	-40~ 85	-40~ 85	-40~ 85
Maximum system voltage	VSYS (V)	1500	1500	1500	1500	1500
Maximum series fuse	ICF (A)	20A	20A	20A	20A	20A
