SC9DT
| Model | Unit | EURO III, Euro III/Euro IV/Euro V | |
| SC9DT280 | SC9DT320 | ||
| Type | In-line, electronically controlled, TCI, 4-stroke, water cooling | ||
| Bore ×Stroke | mm | 114×144 | |
| Total displacement | L | 8.8 | |
| Rated power/rated speed | kw/r/min | 206/2200 | 235/2200 |
| Maximum torque/speed | N.m/r/min | 1120/1400 | 1250/1400 |
| Min. fuel consumption | g/kw.h | ≤215 | |
| Noise | dB(A) | ≤96 | |
| Overall dimension | mm | Length: 1345, Width: 715, Height: 1075 | |
| Net weight | kg | 760 | |
| Power range | ps | 280~320 | |
