Frequency Adjustable Vibratory Finishing Machine

Frequency Adjustable Vibratory Finishing Machine
Frequency Adjustable Vibratory Finishing Machine
Frequency Adjustable Vibratory Finishing Machine
Request a Quote

The frequency adjustable vibratory finishing machine is equipped with automatic separation system, which can automatic separate the finishing media and workpiece. After the sufficient grinding driven by vibration motor, the abrasive will drop through the screen while the workpiece will be automatic discharged. The vibratory polishing machine with separating section makes it easier to separate media and parts, the screen can be customized according to the specifications of the abrasive and products. This design reduces manual labor and greatly boosts the working efficiency.

Parameters
Model Capacity (L) Motor Power (kw) Speed (m/min) Amplitude (mm) Lining Thickness (mm) Weight (kgs) Size L*W*H (mm)
CL-40A 40 0.55 1450 0.8-3 6-12 65 600*500*600
CL-60A 60 0.75-1.1 1450 0.8-3 6-12 100 700*640*700
CL-80A 80 1.1 1450 0.8-3 6-12 110 840*640*740
CL-95A 95 1.1 1450 0.8-3 6-12 125 860*800*750
CL-135A 135 2.2-3.0 1450 0.8-4 6-15 350 1150*1060*900
CL-150A 150 2.2-3.0 1450 0.8-4 6-15 380 1150*1050*900
CL-350A 350 5.5 1450 0.8-6 6-20 800 1450*1350*1050
CL-450A 450 5.5 1450 0.8-6 6-20 1000 1550*1430*1050
CL-650A 650 7.5 1450 0.8-8 6-20 1500 1900*1850*1300
