Offset Printing Machine (Movable Delivery Table)

Offset Printing Machine (Movable Delivery Table)

Descriptions of Offset Printing Machine (Movable Delivery Table)
1. The maximum printing image is 330×445mm, so the printing machine can meet more requirements than the other kinds of printing machines.
2. The machine is equipped with a movable delivery table, so it is easy to use and can save more time.
3. High Performance in printing operation: There are three ink form rollers which can keep the ink more uniform than ever before.

Features of Offset Printing Machine (Movable Delivery Table)
Control panel/Computer control/Convenient and reliable/Window display/Easy to see
1. Micro-computer controlling system is available; so it makes number printing and showing printing speed selecting much easier than before.
2. A unique self-diagnose function may help you find and eliminate the fault quickly. The program edition system makes fault diagnosing much easier.
3. We can read the preprinting number and printing speed from the control panel directly when the key on the control panel is pushed down lightly.
4. The fault indicating can be saw from the monitor table up and down, like double-sheet detection in paper feeding and delivery paper jamming etc.

Technical Parameters of Offset Printing Machine (Movable Delivery Table)
Max. Printing Image 330mm 445mm
Paper Size Max.340mm 483mm
Paper Weight 28-255g/m2
Printing Speed 2000-9000SPH
Paper Feed Suction
Delivery Chain
Capacity of Feed Table 400mm
Capacity of Delivery Table 420mm
Total Rollers 14 pieces(3 ink form rollers)
Dimension 1235×840×1285mm
Counter LED display. pre-set. 4 digits
Double-Sheet Detection Range 28-255g/m2
Consumption Power 850W
Power Supply Single phase 220V 50Hz
Gross Weight 400Kg
