High-efficiency Indoor IP20 2835 SMD White LED Strip Light

: http://ledstripsolution.us/2-3-high-efficiency-indoor-white-led-strip-light.html

Key Features

Ambient Temperature: -20℃ to 45℃
Voltage: DC24V
Length/Reel(M/ft): 5m/16.4ft
High luminous efficacy up to 180lm/W. Higher brightness provided under the same power
Non-waterproof but dustproof, ideal for indoor lighting projects
4000K natural white light, best for household lighting
Good light color consistency. Color tolerance within 3 SDCM
Premium 3Oz copper FPC circuit board delivers stable light quality

*Please contact our sales for the latest details and certifications

Specification

Model	Led Qty	Power	Lumens per feet	Cutting increment	LED pitch	PCB width
FH05W-P0-G1 28HX8x 24V70S W08L05	70LEDs/M	4.8W/M 1.46W/ft	780lm/M 238lm/ft	100mm 3.94˝	14.3mm 0.56˝	8mm 0.31˝
FH10W-P0-G1 28HX8x 24V140S W08L05	140LEDs/M	9.6W/M 2.93W/ft	1500lm/M 457lm/ft	50mm 1.97˝	7.1mm 0.28˝	8mm 0.31˝
FH14W-P0-G1 28HX8x 24V210S W10L05	210LEDs/M	14.4W/M 4.39W/ft	2220lm/M 677lm/ft	33.3mm 1.31˝	4.8mm 0.19˝	10mm 0.39˝
FH05W-P0-G1 28HX8x 24V64S W08L05	64LEDs/M	4.8W/M 1.46W/ft	800lm/M 244lm/ft	125mm 4.92˝	15.6mm 0.61˝	8mm 0.31˝
FH10W-P0-G1 28HX8x 24V128S W10L05	128LEDs/M	9.6W/M 2.93W/ft	1600lm/M 488lm/ft	62.5mm 2.46˝	7.8mm 0.3˝	10mm 0.39˝
FH12W-P0-G1 28H2G8x 24V80S W10L05	80LEDs/M	12W/M 3.66W/ft	2260lm/M 689lm/ft	100mm 3.94˝	12.5mm 0.49˝	10mm 0.39˝

Note:'x' (CCT) ="24"(2400K) / "27"(2700K) / "30"(3000K) / "40"(4000K) / "50"(5000K) / "60"(6000K),Please contact us for more information.
