JMQ930 Automatic Flatbed Die Cutting Machine
The JMQ930 automatic flatbed die cutting machine is a kind of die cutting equipment offered for processing various kinds of common paper and PE coated paper. It is extensively used in printing industry, packaging industry, and paper cup industry.
The roll paper is delivered to the flatbed cutting device by the stepping motor. Conveniently and accurately, the paper feed can be adjusted on the display. This high speed flatbed die cutter can be used for cutting both white paper and printed paper. Utilizing pneumatic clutch, the operation of the automatic flatbed die cutting machine is rapid and reliable. The special finished product stacking mode features safety, convenience, and orderliness.
Technical Parameters of Automatic Flatbed Die Cutting Machine| Model | JMQ930 |
| Max. Cutting Size | 880×500mm |
| Cutting Length | <25m |
| Operation Speed | 60-110 times/min, based on paper thickness |
| Main Motor Power | 7.5kW |
| Applicable Raw Material | 50-450g/m2 |
| Air Source | 0.6m3/min, 0.8MPa (prepared by customer) |
| Weight | 5.5 tons |
| Overall Dimensions | 4550mm×2100mm×1700mm |
