Hydraulic Envelope Die Cutting Machine

Hydraulic Envelope Die Cutting Machine
: http://printingmachinecn.com

The hydraulic envelope die cutting machine delivers high efficiency and steady performance due to the fine adjustment of orientation, four columns supporting structure and other advantages. It is capable of automatic separating the paper from the die and automatic stopping.

Developed based on market demand, this product is applicable for cutting off soft moulding material like paper. This machine is well received by virtue of accurate positioning, micro adjustment, automatic stop system, automatic paper withdrawal, easy and safe operation, and wide applications.

Specifications
Technical parameter
Effective working size 800×500mm
The pressure of die cutting 11T
The pressure in oil pump 6.3Mpa
Motor power 2.2kW
Weight of machine 1.6T
Dimensions of machine 1330×870×1450mm
