1CT/1DT Metric Male 24˚ Cone Hose Adapter, DIN Standard
Application: for use with hydraulic braided hoses
Materials:- Stainless steel metric male 24˚cone hose adapter, DIN standard
- Carbon steel metric male 24˚cone hose adapter, DIN standard
| Part No. | Thread | Tube O.D. | Dimensions | Pressure Mpa | |||||
| E | F | D1 | I1 | L1 | S1 | S2 | |||
| 1CT-12-02SP | M12×1.5 | R1/8"×28 | 6 | 13 | 28 | 12 | 14 | 25 | |
| 1CT-14-04SP | M14×1.5 | R1/4"×19 | 8 | 16.5 | 31.5 | 17 | 17 | | |
| 1CT-16-04SP | M16×1.5 | R1/4"×19 | 10 | 17.5 | 32.5 | 17 | 19 | | |
| 1CT-18-06SP | M18×1.5 | R3/8"×19 | 12 | 18.6 | 33.6 | 19 | 22 | | |
| 1CT-22-08SP | M22×1.5 | R1/2"×14 | 15 | 22.8 | 37.8 | 24 | 27 | | |
| 1CT-26-12SP | M26×1.5 | R3/4"×14 | 18 | 22 | 38.5 | 30 | 32 | 16 | |
| 1DT-14-04SP | M14×1.5 | R1/4"×19 | 6 | 21.5 | 36.5 | 17 | 17 | 40 | |
| 1DT-16-04SP | M16×1.5 | R1/4"×19 | 8 | 21.5 | 36.5 | 17 | 19 | | |
| 1DT-18-06SP | M18×1.5 | R3/8"×19 | 10 | 21.1 | 37.6 | 19 | 22 | | |
| 1DT-20-06SP | M20×1.5 | R3/8"×19 | 12 | 23.1 | 39.6 | 22 | 24 | | |
| 1DT-22-08SP | M22×1.5 | R1/2"×14 | 14 | 27.8 | 45.8 | 24 | 27 | | |
| 1DT-24-08SP | M24×1.5 | R1/2"×14 | 16 | 27.3 | 45.8 | 27 | 30 | | |
