ESD-V24-025S 24VDC 25W Dimmable LED Power Supply
Features
- This dimmable LED power supply has a a internationally universal full range input (100~277VAC).
- It is equipped with built-in intelligent identification CPU of light and heavy load (the light can be dimmed completely).
- The LED power supply has short-circuit protection, over-temperature protection, overload protection and other functions, making it more secure to use.
- The power efficiency is as high as 85%.
- This LED power supply has three-in-one dimming function (0-10V DC, PWM, resistance).
- This dimmable power supply has a built-in power factor corrector.
Basic Parameters
| Input voltage | 100~277VAC 50/60Hz |
| Input current | 0.35A Max |
| Output voltage | 24VDC |
| Output current | 1.05A Max |
| Output power | 25W |
| Power factor | >0.95 |
| Power efficiency | 85% |
| Size | 330×21×20mm |
