Jelly Candy Production Line Manufacturer

Jelly Candy Production Line

: http://shfoodmachine.com

Jelly Candy Production Line

The QH150Q/300Q/450Q/600Q jelly candy production line is developed by the advanced production technology based on the market demand of jelly candies with multiple shapes or colors. As the ideal equipment to continuously produce high class jelly candies, our product can produce QQ candies with single or double colors. High-quality jelly candies with various shapes and colors can also be made by replacing the moulds or pouring head. The quantitative filling and mixing of essences, pigments and acid liquor can be completed on line. The highly automatic production can not only produce candies with stable quality but also save manpower and space so as to reduce production costs.

Specifications

Model	QH150Q	QH300Q	QH450Q	QH600Q
Standard Production Capacity	150kg/h	300kg/h	450kg/h	600kg/h
Candy Weight	2-8g
Pouring Speed	55-65 time/min
Requirements of the Working Environment	Temperature 20-25℃, humidity 55%
Total Power	32KW/380V	39KW/380V	48KW/380V	75KW/380V
Length of the Entire Line	17m	17m	18m	18m
Total Weight	3000kg	3500kg	4000kg	4500kg

In order to meet the needs of different customers, our company provides four types of jelly candy production line with the standard production capacity of 150kg/h, 300kg/h, 450kg/h and 600kg/h. With the length of 17m or 18m, our product can complete the whole process of sugar dissolving, filtering, cooking, cooling, adding additives, pouring, stripping and packaging. It can produce candies weighing 2 to 8g. To ensure the stable operation as well as long life, the equipment should work in environment with the temperature of 20-25 ℃ and the humidity of 55%.

Pictures of the produced products are shown below.
