T Series LED Track Lighting Head with Built-in Drive
Features
- The T series LED track light features an anti-glare design. The light is soft, not dazzling.
- The color render index (CRI) is Ra97+(2700K/3000K/4000K), which displays the natural color of objects
- The LED driver of the track light is of high quality, high efficiency, energy saving.
- T series LED track lights have different dimming options, such as DALI, TRIAC, 0/1-10V, DMX, RF, ZigBee.
- We provide three kinds of track adapter with 1 phase, 2 phase or 3 phase for you to choose from.
- Five kinds of power: 20W/25W/30W/35W are available.
Specification
- LED Chip Citizen/CREE COB
- LED Driver Tridonic, Philips, OSRAM, Lifud, BOKE and other brands
- Dimming option Non-dimming, DALI, TRIAC, 0/1-10V, DMX, RF, ZigBee
- PF >0.9
- THD <12%
- Input Voltage AC220-240V/ AC100-240V 50/60Hz
- CRI 80+90+97+
- CCT 2700K, 3000K, 3500K, 4000K, 5000K
- Luminous Efficacy 90-100lm/W @CRI80 (whole lamp)
- Body Material 6063 brushed aluminum alloy
- Light color Warm white, pure white, cold white
- Adjustable 350° rotation horizontally and 90° pivot
- Housing color Black/white/silver
- Track adapter Global, PowerGear and other brands are available
- Track adapter phase 1 /2 /3 phase
- Lifespan 50000 hours
- Warranty 3-5 Years
Dimension
Product Models
| Model No. | Power | Dimension | LED Chip | CCT | CRI | Luminous Efficacy | Beam Angle | Input Voltage | Track adapter | |
| BH-TL-20W-T | 20W | Φ90x190mm | Citizen/ CREE COB | 2700K 3000K 3500K 4000K 5000K | 80+ 90+ 97+ | 100-110lm/W @CRI80 | 15°/24°/ 36°/60° | AC220-240V/ AC100-240V 50/60Hz | 1 phase 2 phase 3 phase | |
| BH-TL-25W-T | 25W | |||||||||
| BH-TL-30W-T | 30W | |||||||||
| BH-TL-35W-T | 35W |
Index
track lighting, track replacement light, LED tracking kits, track light fixture
