Full HD Endoscope Camera System, INP-200 Manufacturer

Full HD Endoscope Camera System, INP-200

: http://endoscope-cameras.com/1-2-full-hd-endoscope-camera-system.html

This endoscope camera is specially made to provide Full HD imaging with 60 frames per second. This Full HD medical camera is durable and cost-effective. It can be widely applied to different hospital departments, like otolaryngology, urology, gynecology and orthopedics.
This endoscope camera can be connected to different imaging accessories to deliver clearer and sharper images, like otoscope, nasal scope, laryngoscope, laparoscope, hysteroscope, arthroscope and spine endoscope.

Highlights

Cost-effective
This endoscope camera is affordable and can capture clear and sharp images.
Multi-form Output
This medical endoscope camera is able to output different formats of images or videos, like DVI/VGA/SDI. It is also applicable to different displays.
Wide Application
This endoscope camera can be connected to different brands of high-frequency electric knives while avoiding causing interference.
Miscellaneous Functions
This endoscopic surgery camera features different functions, for instance, image freeze allows for deeper examination during the surgery.

Features

This endoscope camera is able to transmit signals in accordance with DVI/VGA/3G-SDI standards;

This medical endoscope camera is equipped with a 1100TVL 1/2.8" SONY CMOS with 2 MP to deliver Full HD imaging with 50/60 frames per second while avoiding image trail effect. It is also equipped with a 5-inch secondary monitor;

This medical imaging machine supports the switch of NTSC menu to PAL menu. It also supports the OSD menu;

The energy cost is relatively small and the camera body will generate little heat during operation;

This endoscope camera can carry out different functions, like white balance, image freeze, anti-fog, anti-reflection and exposure compensation;

This medical imaging camera is driven by an AC220V power supply and can work in places with the temperature ranging from -10°C to 50°C. It is also equipped with power surge protector with 500V clamping voltage and can avoid harms caused by static electricity, with the protection of contact electricity discharge reaching 8 kV and the air discharge reaching 15 kV;

Able to be connected with different endoscope camera in different departments while avoid causing interference to high-frequency electric knife;

Specifications

Input port: TFGG push-pull self-latching connector

Video output: DVI/3G-SDI (digital), VGA (analog)

Synchronization mode: internal synchronization

Input power: ≤100VA

Safety fuse: F2A250V×1, F3.15A250V×2

Voltage: 220V

Frequency: 50Hz

Operation temperature: 5~ 40℃

Storage temperature: -20~ 55℃

Humidity: 30%-80%, no condensation

Atmospheric pressure: 50kPa~106kPa

SNR (signal to noise ratio): greater than 50dB (AGC off)

Minimum illumination: 1Lux (color), 0.5Lux (black/white)

Resolution: 1920*1080P@60fps, maximum 1100 TV lines

Frame rate: 50/60 fps

OSD (on-screen display) menu: available

White balance: button

Screen freeze: button

Rated power: up to 20W

Standards: GB9706, YY0505, GB/T14710, CE, ROHS

Brightness: 0~20 adjustable, default 7

Sharpness: 0~10 adjustable, default 7

Color saturation: 0~20 adjustable, default 10

Gain: 0~10 adjustable, default 10

Gamma: 0.45~0.75, default 0.55

Format: PAL/NTSC, default PAL

Language: English, Simplified Chinese, Traditional Chinese, Japanese, Korean, Russian, Spanish

Dimensions: 380mm×300mm×115mm

Weight: 4.6kg
